480-990KW Imodoka y'umuyagankuba DC EV Ikibanza co gushaja
Ico kibanza co gushaja amashanyarazi gifise ubushobozi bwa 480–990 kW DC ni ubuhinga bwo gucapura amashanyarazi menshi -bugenewe gushaja vyihuta kandi vyizewe vy’ibinyabiziga vy’ubudandaji n’ibinyabiziga bikeneye cane. Ifise ubuhinga bwo gutanga amashanyarazi buhambaye kw’isi yose, ubushobozi buhoraho bwa ultra-, n’ubugenzuzi bw’ubwenge bwo gutanga amashanyarazi neza. Ifise IP65-rated modules, uburinzi bukora ku muriro urengeje urugero, umuriro urengeje urugero, n’ugusubira inyuma, n’amahitamwo y’amazi-akonjeshwa, bituma bikora neza kandi bikora neza cane no mu bidukikije bikomeye.
Iciyumviro n'insobanuro y'igicuruzwa
Inguvu zo gushaja
480–990 kW ifatwa nk’Inguvu nyinshi-Ishaja ryihuta ry’umuriro (HPCC), ryiza ku bibanza binini vy’ugushaja vyihuta vya bose canke ibibanza vy’ugushaja vyihuta ku nzira ndende.
ukudahuza:
- Gushaja buhoro mu nzu: 3–22 kW
- Ubucuruzi AC kwihuta gushaja: 50 kW
- Inguvu nyinshi zo gushaja: 150-350 kW (zisanzwe), 480-990 kW (inguvu nyinshi cane)
Abakoresha n'Ibikorwa
- Ibibanza vy'amabarabara manini, ibibanza vy'ubuhinga, ibibanza binini vyo guhagararako imodoka mu bisagara, n'abakoresha urubuga rwo gushaja.
- Gushimikira kuri bisi nini zikoresha umuyagankuba, amakamyo y’umuyagankuba, n’ibinyabiziga vy’abantu bigenda kure-.
Itunganijwe neza ku vyo ukeneye mu gushaja
Inguvu nyinshi cane
Itanga ubushobozi bushika kuri 990 kW DC n’ubushobozi bwo hejuru bwa 96%, igabanura igihe co gushaja ku mato y’ubudandaji n’ibinyabiziga bikeneye cane-.
Uburyo bwo gushaja
Ishigikira umwanya-, inguvu-, umubare-, canke SOC-ishingiye ku gutanga amafaranga n'uguhindura intwaro zibiri-, igihe kimwe, canke gutanga amafaranga bitegekanijwe kugira ngo bikore neza.
Ukoresha-Ikigaragara c'ubugenzi
10.1-inch touch display itanga ibikorwa vyoroshe, inyishu y’ugushaja mu gihe nyaco, n’ugushiramwo vyoroshe mu mirongo y’uburongozi.
Uguhuzwa kw'ubwenge
Ishigikira OCPP 1.6, Ethernet, 4G idasanzwe, n’ubugenzuzi bushingiye kuri app-, bushoboza gukurikirana kure, gupima amakosa, no gukorana neza n’uburongozi bw’ubwato.
Gukonjesha amazi biteye imbere
Ivyo gukonjesha amazi incuro zibiri-bituma ubushuhe bw’imbunda buguma munsi ya degre 55 kugira ngo bukomeze gushaja, bikoresha amazi akonjesha, kandi birimwo ugukurikirana umuvuduko, uruja n’uruza, n’ubushuhe kugira ngo bibe vyiza.
Umutekano wose
Ifise ama contactors, ama fizi, guhagarika vyihutirwa, umuriro urenze urugero, umuriro urenze urugero, umuriro urengeje urugero, n’uburinzi bwo gusohoka, hamwe n’uburinzi bw’ibikoresho n’ubuhinga.
Ibisobanuro
|
Ibirango vy'injiza
|
Injiza umuriro
|
400 Ubusa ± 10%
|
|
Incuro zo kwinjiza
|
50 / 60 Hz
|
|
|
Ubwoko bw'injiza
|
3P + N + PE
|
|
|
Injiza ubu
|
733/916/1100/1283/1466/1512 A
|
|
|
Inguvu zo kwinjiza
|
480/600/720/840/960/990 kW
|
|
|
Igiharuro c'ububasha
|
0.99
|
|
|
Ubuhinga
|
<5%
|
|
|
Ibirango vy'Igisohoka ca DC
|
Igisohoka kinini
|
1000A(amazi-akonjeje cane)
|
|
Inguvu zigereranywa
|
480/600/720/840/960/990 kW
|
|
|
Ubushobozi bwo hejuru
|
96%
|
|
|
Ishusho
|
IP na IK igitigiri
|
IP54 na lK10
|
|
Ingano
|
2651*2083*950mm
|
|
|
Uburemere
|
Muto canke bingana n'ibiro 2381
|
|
|
Injiza ya DC
|
Injira y'umuriro
|
200V-1000V
|
| Igisohoka ca DC |
Amahitamwo y'umuhuza
|
CCS2.
|
|
Igisohoka c'umuriro
|
200-1000 V
300~1000V ni umuriro w'isohoka w'inguvu zidahinduka
|
|
|
Igisohoka kinini
ububasha
|
240kW (Ikibanza gisanzwe)
990kW(amazi- akonjejwe)
|
|
|
Igisohoka kinini
ubuhinga
|
300A (Ikibanza gisanzwe)
1000A (Igikoresho co gukonjesha amazi-
|
|
|
Ibigize
|
Uburebure bw'umugozi
|
5m (4.5m zigaragara kuva ku gicapo)
|
|
Ingano n'uburemere
|
Igikoresho co gushaja:803*600*2003mm Muto canke kingana na 215kg
1098*910*2192mm Bike canke bingana na 395 k
|
|
|
Ishusho
|
10.1 inci
|
|
|
Umusomyi wa RFID
|
ISO 14443 A + B ku gice ca 4 na ISO/IEC 15693, Mifare1, NFC
|
|
|
Buto y'ivyihutirwa
|
Egome
|
|
|
Ibidukikije
|
Uburebure bw'ibikorwa
|
<2000 m
|
|
Ubushuhe bwo gukoresha
|
-30 degre ~50 degre (Ububasha bwose)
|
|
|
Ubushuhe bwo kubika
|
-30 degre ~70 degre
|
|
|
Ubushuhe
|
5 %-95 % Rh idakora
|
|
|
Abandi
|
Ikigaragaro c'itumanaho
|
Ethernet (ubusabe 4G)
|
|
Amasezerano y'itumanaho
|
OCPP1.6
|
|
|
Uburyo bwo gukonjesha
|
Umuyaga warakonjeshejwe
|
|
|
Uburyo bwo kwishura
|
RFID / Porogaramu
|
|
|
EMC
|
Ishure A (inganda)
|
|
|
Uburinzi
|
Uburinzi bw'umuriro muto, Uburinzi bw'umuriro urengeje urugero, Uburinzi bw'umuriro urengeje urugero wa DC,
Uburinzi bw'ubushuhe burenze -,
Igikoresho co gukingira umuyaga, uburinzi bwo guhagarara vyihutirwa
|
|
|
Ivyagezwe n'Ivyemezo
|
Amasezerano
|
DIN 70121/ISO15118
|
|
Ivyagezwe
|
RU IEC 61851-1:2019 RU 61851-23:2014 RU 61851-24:2014 RU IEC 61851-21-2:
2021
|
|
|
Ikimenyetso c'ivyemezo
|
SGS CE .
|
Uburyo bwo guhingura n'ubwubatsi
Ikirundo kimwe co gushaja n'Ikigo c'Itsinda
- Ivyuma vy’ugushaja amashanyarazi menshi-mu bisanzwe birimwo ibirundo vy’ugushaja 3–6 canke birenze bifatanye mu buryo bumwe, n’inguvu zose zishika kuri 990 kW.
- Bishigikira gucagura icarimwe imodoka nyinshi, ariko bisaba ubuhinga bwo gutanga amashanyarazi.
Uguhuza uruzitiro n'uburongozi bw'amashanyarazi
- Ubufatanye bw'ugutanga umuriro w'umuriro munini -: 35 kV/10 kV/ubufatanye bw'umuriro muto -
- Isonga-uburongozi bw'amashanyarazi y'ikiyaya: Burinda ingaruka ku ruzitiro rw'amashanyarazi rwo mu karere; birashobora gukoreshwa n’Ubuhinga bwo Kubika Inguvu z’Ibateri (BESS)
- Igikoresho c’ubushobozi n’ubugenzuzi bw’amajwi: Bitegerezwa guhura n’ibitegekanijwe n’uruzitiro kugira ngo bigabanye ingaruka z’umuzigo ku ma transformateur n’imirongo.
Ingamba zo gucunga inguvu
- Dynamic power allocation: Ihindura ubwo nyene ubushobozi bw’imbunda yose ishaja bivanye n’umubare w’ibinyabiziga bishaja icarimwe be n’ingene imbunda ishaja (SOC).
- Gukurikirana ubushuhe: Bibuza module gushuha cane bishobora gutuma igabanuka canke ihagarara.
- Igabanuka ry’isonga: Rifatanya n’uburyo bwo gutanga amakuru kugira ngo ryiza igiciro co kwishura.
Ibice vy'ubuhinga
Inguvu zo guhindura ibice
- AC→DC Gukosora: Ihindura ubushobozi bw’uruzitiro rwa AC bukaba ubushobozi bwa DC.
- DC/DC Boost/Buck: Ihindura umuriro w’isohoka bivanye n’ivyo bateri isaba (mu bisanzwe 200–1000 V).
- Igishushanyo c’ibice: 480–990 kW mu bisanzwe ikoresha uburyo bwo gukora ibice vyinshi-bihuye, igice kimwekimwe cose kikaba gishobora kuva kuri 100–250 kW, bikaba vyoroshe kwagura no gusubiramwo.
Amasezerano n'ingingo ngenderwako zo gushaja
- DIN 70121/ISO15118
- RU IEC 61851-1:2019 RU 61851-23:2014 RU 61851-24:2014 RU IEC 61851-21-2:2021
- Ivyuma bibiri-imbunda bituma ikintu kimwe gishobora gucakira ningoga amabateri y'umuriro mwinshi ashika kuri 1000 V, akwiriye amabisi, amakamyo, n'ibinyabiziga vy'abantu bigenda kure.
Uburyo bwo gukonjesha
- Gushaja kw'inguvu nyinshi-bitanga ubushuhe bwinshi, bikaba bisaba guhingura uburyo bwo gukonjesha amazi canke uburyo bwo gukonjesha umuyaga ku nguvu.
- Igikoresho co gushaja gikoreshwa n'amazi: 1098*910*2192mm Muto canke bingana n'ibiro 395
- Gukonjesha bipfutse ibice vy'ububasha, imbunda zo gushaja, n'imirongo, bikaba bituma bikora neza igihe kirekire no mu gihe habayeho ugusaba kw'ububasha bwinshi.
Ubwenge bwo kugenzura no guhanahana amakuru
- Infashanyo y'ubwenge: OCPP 1.6, Ethernet, ubusabe 4G, n'ubugenzuzi bushingiye kuri porogaramu-
- Imodoka-Ikibanza co Gushaja: Ikoreshwa mu kumenya ubwoko bw'imodoka, gushigikira gushaja mu buryo bw'ubwenge, no kugenzura ubushobozi buhinduka.
- Inyuma-iherezo Uburyo bwo Gucungera (CMS/EMS): Gutanga ubushobozi, gushaja ku rutonde, no kugenzura uko ibintu vyifashe.
Uguhuza kwa bateri n'ibiranga gushaja
Ubwoko bwa bateri
- Litiyumu itatu, litiyumu icuma fosifate, umuriro mwinshi-ukomeye-amabateri
- Bateri zitandukanye zifise ubushobozi butandukanye bwo gushaja, umuriro, n’imipaka y’ubushuhe.
Uburongozi bw'umurongo wo gushaja
- Intambwe y'intango y'inguvu nyinshi - → Igice c'ubushobozi buhoraho hagati n'inguvu zidahinduka → Igice c'inguvu z'iherezo zo kugabanya
- Inguvu zo gushaja zishobora guhindurwa zirinda ubuzima bwa bateri.
Inyungu z'ibibanza vyo gushaja DC bifise ubushobozi bwinshi
Umutekano w'umuyagankuba
Gukurikirana ivy'ukwikingira, gukingira ukuvuza, n'ugufatanya kw'umuriro mwinshi bituma gushaja bigenda neza.
Ivyuma vyihuta-bikora vyihuta -ibicapura n'amafuzi bitanga ukwitandukanya kw'amakosa vyihuta n'uburinzi bw'ibikoresho.
Uburongozi bw'ubushuhe n'uburinzi bw'umuriro
Ubuhinga bwo gushaja bukonjeshejwe n'amazi-bufasha gukora neza munsi y'inguvu nyinshi -ikomeza gusohoka.
Ivyiyumviro vyo kumenya umuriro no kuwuzimya (uguzimya gazi canke gutera amazi) bituma ikibanza-kingira umutekano ku rugero rwo hejuru.
Umutekano w'itumanaho
Ugushiramwo amakuru bituma habaho umutekano wo gutanga amakuru y'ugushaja n'ay'abakoresha.
Uburyo bwo kwemeza umuntu burabuza umuntu kwinjira ata wemerewe.
Ukwirinda kwinjira kure bituma sisitemu ishobora kwizigirwa.
Gukurikirana kure
Igihe nyaco-gukurikirana uko ibintu vyifashe, inkengeri zidasanzwe, n'ugusubiramwo porogaramu nkuru.
Imibare y'ikoreshwa ry'inguvu n'isesengura ry'amakuru y'imikorere birafasha mu gutuma ibikorwa bigenda neza.
Ukwitaho ibice
Ubwubatsi bw'ibice bushobora gusubirira vuba ku -urubuga, kugabanya igihe co guhagarara.
Gusanasana kwa misi yose birimwo gusuzuma amazi akonjesha, gusuzuma ko intsinga zambaye, no gukomeza amahuzu y'umuyagankuba.
Icitegererezo c'ubucuruzi
Ivyitegererezo vy'ugutanga amafaranga bihinduka: ku kWh, kw'isaha, canke kwiyandikisha-bishingiye ku gutanga amafaranga.
Gushigikira ubufatanye n'abakoresha amabarabara, amashirahamwe y'ivy'ubuhinga, n'abakoresha amato kugira ngo bagure imihora yo gushaja.
- Imigenderanire y'uruzitiro:Ishigikira ubushobozi bwinshi-gushaja icarimwe n'ugutanga ubushobozi bw'ubwenge n'ugushiramwo BESS kugira ngo ugereranije imizigo y'isonga.
- Uburongozi bw'ubushuhe:Ivyiza vy’umuyaga- n’amazi-ivyo gukonjesha bituma bikora neza ku 480–990 kW zikomeza.
- Gushaja bihuye:Ishigikira ibigereranyo vyinshi vy’imodoka, amashanyarazi, n’amategeko asanzwe (DIN 70121 / ISO15118 / CCS2) kugira ngo ikoreshwe cane.
- Ubutunzi bukora:Igishushanyo c’ibice, ugukurikirana kure, n’ugutegura urutonde rw’ibintu mu buryo bw’ubwenge bituma ikoreshwa ryinshi kandi bikagabanya ibiciro vy’Ibikorwa n’Ibikorwa.
- V2G (Imodoka-ku-Uruzitiro) kwitegura:Ishigikira uruja n'uruza rw'inguvu zijanye n'inzira zibiri ku bijanye n'amategeko y'uruzitiro n'ugushavura kw'isonga aho bishobotse.
- Ugushiramwo ububiko bw'inguvu:Ugushiramwo BESS mu buryo butari bwo biratuma ivyipfuzo vy’isonga bigenda neza kandi bikagabanya umukazo wo kwagura uruzitiro.
- Ubushobozi bwo kuvugurura ibice:Inguvu z’ibarabara zirashobora kwagurwa mu buryo buhinduka kugira ngo zihure n’ivyo imodoka zizosaba n’inguvu zo muri kazoza.
- Urutonde rw'ubwenge:AI n'amakuru manini bishoboza gutanga ubushobozi neza, guhagarara ku murongo w'imodoka, no gukoresha neza igiciro co kwishura.
Ku bakoresha amashaja n’abategura ivy’ugutwara abantu n’ibintu mu bisagara, ibibanza vyo gucapura vyihuta vy’amashanyarazi 480–990 kW DC si ugutera imbere kw’ubuhinga gusa, ariko kandi ni ikintu gishasha co gukura ku gaciro k’ubudandaji. Biciye mu gutanga amashanyarazi mu buryo bw’ubwenge, gushaja icarimwe imodoka nyinshi, no kuzigama neza ingufu, izo nzira z’amashanyarazi zishobora gutuma zishaja neza, zigabanya amafaranga yo gukoresha no kuzibungabunga, no gutanga ibikorwa remezo vyizigirwa ku isoko rishasha ry’imodoka zikoresha inguvu, zikaba infashanyo nyamukuru y’ubuhinga bwo gutwara abantu n’ibintu muri kazoza.
